IEC60227 Compliant Cable Bending Test Apparatus with 0.5KG Test Load and 60r/min Oscillating Speed

Name: IEC60227 Compliant Cable Bending Test Apparatus with 05KG Test Load and 60rmin Oscillating Speed
Brand: Pego Electronics
Price: 1000 USD

Brand Name : Pego Electronics

Model Number : PG-CBT

Certification : CNAS Calibration Certificate

Place of Origin : China

MOQ : 1 set

Price : USD1000~USD5000

Payment Terms : T/T

Supply Ability : 50 set/months

Delivery Time : 10-20 working days

Packaging Details : woodencase

Normative Standards : IEC60227-2, IEC60227-1

Application : for checking the mechanical strength of completed cables

Test Current : 0.1A

Test Load : 0.5KG

Oscillating Speed : 60r/min

Swing Angle : ±90 degrees on both sides from vertical

Control Unit : PLC+touch screen

Input : 220V, 50Hz/60Hz

Contact Now

Cable Bending Test Apparatus for Checking Mechanical Strength of Complete Cables Compliant with IEC60227

Introduction

The cable bending test apparatus is designed to meet the test requirements of IEC60227-2:2003 clause 3.2 and IEC60227-1:1998 clause 5.6.3.2 for checking the mechanical strength of completed cables.

A sample of cord of appropriate length is fixed in the apparatus, and loaded with a weight having a mass of 0.5KG. A current of about 0.1A shall be pass through the conductors. The sample shall be bent backward and forwards in a direction perpendicular to the plane of the axis of the conductors, the two extreme position making a angle of 90° on both sides of the vertical. A flexing is a movement through 180°. The rate of flexing is 60 per minute. Neither interruption of the current nor short circuit between the conductors shall occur.

2. Specification

Working power	220V/50Hz, 300W max
Control system	7 inch LCD touch screen+PLC
Load weights	0.5KG
Working station	1
Oscillating speed	60r/min
Oscillating drive	Step motor
Test times	0-99999 (preset-able)
Oscillating angle	Free setting
angle indicator	0-360^°, made of stainless steel
Swing angle	±90^°on both sides from vertical
Output current	0.1A
Output power (max)	50W
